CLINDIAG SA-20 Semi-auto Biochemistry Analyzer

(0 reviews)

CLINDIAG SA-20 Semi Auto Biochemistry Analyzer
Brand	CLINDIAG
Model	SA-20
Country of Origin	Belgium
Warrenty	01 Year
Weight	8.5 kg

Category: Diagnostic

Subcategory: No Subcategory

Tags: #Analyzer #Biochemistry Analyzer #Diagnostic Products #Hormone Analyzer #MediBazarBD #Microplate Reader

110,000.00 BDT 140,000.00 BDT

CLINDIAG SA-20 Semi Automatic Biochemistry Analyzer:

SA-20 Semi Automatic Biochemistry Analyzer

Features

End point, kinetic, fixed time, mutistandard, bichromatic etc
Filter wavelengths: 7standard filters from 340 to 800nm, 2 more open filter positions, others are available on request
With 20 incubating positions
Large memory to store 200 test programs and 1000 testing results
Excellent Q.C function Q.C. chart can be stored, displayed and printed.

Technical Specifications

Reading Cuvette: Both through cell and direct reading cuvette
Incubating Positions: 20 incubation positions
Photometric System:
Light Source: 6V 10W long-life halogen lamp
Filters: 7standard filters from 340 to 800nm, 2 more open filter positions; ±2 nm pass-band
Wavelength Accuracy: ±2 nm
Measuring System: Measuring Range: 0-3.500 O.D
Photometric Linearity: ±2% from 0 to 2.000 O.D.
Photometric Accuracy: ±2% from 0 to 2.000 O.D.
Drift: less than 0.001 O.D.
Carry Over: ≤1%
Incubator Temperature control: 25degree.centigrade ,30degree.centigrade ,37degree.centigrade, Precision:±0.1degree.centigrade
Reagent Volume: 200-500 ul
Printer: Built-in thermal printer, 57mm width paper
Power Supply: 110V 60HZ / 220V 50HZ, 60VA
Dimensions: 34cm*38cm*18cmWeight: 8.5kg
